Parts included
F
A
B
C
D
E
G
H
I
J
A NSO evo3S Marine Processor Unit (MPU)
B MPU Power cable, 2 m (6.5')
C Micro-C power cable, 1.3 m (4.3')
D Micro-C drop cable, male-female plugs, 1.8 m (6')
E Micro-C T-connectors (x3)
F Micro-C terminators, 120 ohm, (male and female)
G NMEA 0183 serial cable, 8 wires, 2 m (6.5')
H Ethernet adaptor, 5 pin female to RJ45 male
I Installation kit:
• Cable retainers (x2)
• Cable ties (x20)
• Pan head screws, 3.5 x 19, A4 DIN7981B (x8)
J Documentation pack
8
Introduction | NSO evo3S MPU Installation Manual
