Offset to cursor position
This option allows you to use the cursor for selecting the antenna center.
When the option is selected, the cursor is displayed on the PPI.
• Move the cursor to the preferred offset position, then press the enter key or the left mouse
key to move the PPI center to the cursor position.
Vectors
A target vector indicates the expected target movement within a defined time. The vectors
are computed by multiplying the target speed with the set time value.
You can select to show target vectors with true or relative speed, and you can set the length
of the vector. The length represents the vessel movement within the given time period.
Vector settings are shown in the target indicators panel (A).
Ú
Note: True speed indication is not possible if there is a gyro or speed source failure. If the
vectors are in true presentation and one of the sensors (gyro or speed log) fails, the
presentation is automatically switched to relative.
Cursor bearings
You can select to show the cursor bearings as true or relative to own vessel.
Ú
Note: True can only be selected when a gyro is available.
Setting the brilliance for panel items
The brilliance can be set individually for the various panel items.
32
Radar view options | R5000 Operator manual
