Simrad R5000 User Manual

Medium pulse 5 MHz
Long pulse 2 MHz
Horizontal Beam width 1.35°
Vertical Beam width 22°
VSWR < 1.20
Overall noise figure < 5 nominal dB
MDS on long pulse -105 dBm
Display features
Presentation mode Day or Night
Typical viewing distance (m)
16" 0.75
19", 24", 27" 1.00
Resolution (pixels)
16", 19" 1366x768
24", 27" 1920x1080
PPI Diameter (mm)
16" 180
19" 210
24" 280
27" 320
Short range
Available scales 1/8, 1/4, 1/2, 3/4, 1.5 and 3 NM
Range video resolution 11.25 m
Azimuth on-screen resolution 0.1°
Medium range
Available scales 6 and 12 NM
Range video resolution 45 m
Azimuth on-screen resolution 0.1°
Long range
Available scales 24, 36, 48, 64, 72 NM
Range video resolution 125 m
Azimuth on-screen resolution 0.1°
Relative Motion (RM)
Head up (HU), Course up (CU) and North up
(NU)
True Motion (TM) Course up (CU) and North up (NU)
Off-centering Up to 75% of range scale in use
Cursor
Polar and Geographical coordinates,
continuously displayed when cursor is
activated
Target tracking
Acquisition Manual and automatic, up to 100 targets
Tracking Manual and automatic, up to 100 targets
Technical specifications | R5000 Operator manual
