There is a direct link between the range scale and the operational mode of the selected radar
sensor.
Range scale
Standard radar operation Target boost radar operation
A B A B
1/8 NM (200m) 0.08/3000 24 0.08/3000 24
1/4 NM 0.08/3000 24 0.08/3000 24
1/2 NM 0.08/3000 24 0.08/3000 24
3/4 NM 0.08/3000 24 0.08/3000 24
1.5 NM 0.08/3000 24 0.08/3000 24
3 NM 0.08/3000 24 0.25/1500 48
6 NM 0.25/1500 48 0.25/1500 48
12 NM 0.25/1500 48 0.8/750 72
24 NM 0.8/750 72 0.8/750 72
36 NM 0.8/750 72 0.8/750 72
48 NM 0.8/750 72 0.8/750 72
64 NM 0.8/750 72 0.8/750 72
72 NM 0.8/750 72 0.8/750 72
A: Pulse length (µS/PRF (Hz)
B: Maximum radar range visibility (NM)
For more information refer to the radar sensor documentation.
Using the cursor
The cursor can be used to measure a distance, to define various radar map elements, and to
acquire and select targets within the PPI area.
By default, the cursor is not active after power on.
To activate the cursor:
• Press one of the arrow keys
• Use the mouse to position the pointer inside the PPI area
When the cursor is active on the radar PPI, the cursor information area will show range and
bearing from the vessel to the cursor position. If the system is connected to a position source
(i.e. EPFS), the cursor information area includes the geographic position of the cursor.
To deactivate the cursor:
• Press the exit key
• Use the mouse to position the pointer outside the PPI area
Selecting speed source
Speed information can be obtained from different speed sources connected to the system.
At any time you can switch the preferred primary speed source to any of the available speed
sensors from the menu.
The stabilization mode depends on the selected speed source. The system will automatically
switch to the available stabilization mode when the speed source is changed.
The table shows stabilization modes available for each speed source type. Any restrictions for
a source are detailed under each speed source description in the following sections.
Speed source
Stabilization mode
available
Restrictions
Speed LOG (Single axis) Sea None
20
Basic operation | R5000 Operator manual
