Technical specifications
The most up-to-date specifications list is available at:
• www.navico-commercial.com
Ú
Note: Hardware specifications for the individual units included in the system are found
in the documentation following the units.
General
Description
Type-approved X- and S-Band radar systems
aboard CAT 1, CAT 2 and CAT 3 SOLAS
vessels, including high-speed craft
Standards • IMO-Resolution A.278 (VIII), A.694 (17), A.
823 (19), MSC 191 (79), MSC 192 (79)
• EN 62388 Ed.2.0, 2014
• EN 62288 Ed.2.0, 2014
• EN 60945 Ed.4.0, 2002 incl. Corr.1, 2008
• EN 61162-1 Ed.4.0, 2010
• EN 61162-2 Ed.1.0, 1999
Type approval European Council Directive 2014/90/EU on
Marine Equipment modified by Commission
Implementing Regulation (EU) 2018/773
(May 2018) - Wheelmark
Performance
RPM >20 and >40
Nominal peak power
X-band up-mast 12 kW or 25 kW depending on transceiver
X-band down-mast 25 kW
S-band 30 kW
Operating frequency
X-band 9410 ± 30 MHz
S-band 3050 ± 30 MHz
Pulse length
Short pulse 60 ns (25 kW, 30 kW), 80 ns (12 kW)
Medium pulse 250 ns
Long pulse 800 ns
PRF
Short pulse 3000 Hz
Medium pulse 1500 Hz
Long pulse 750 Hz
Modulator MOSFET Solid State
IF amplifier Logarithmic
IF dynamic 95 dB
IF center frequency 60 MHz
IF bandwidth
Short pulse 24 MHz
20
78
