Hazard distances
Configuration
Distance 100 W/m
2
point (m)
Distance 50 W/m
2
point (m)
Distance 10 W/m
2
point (m)
12 KW Transceiver
6' X-band Antenna
- 0.15 0.6
12 KW Transceiver
9' X-band Antenna
- - 0.5
12 KW Transceiver
12' X-band Antenna
- - 0.35
25 KW Transceiver
6' X-band Antenna
0.1 0.2 1.3
25 KW Transceiver
9' X-band Antenna
- 0.1 1.0
25 KW Transceiver
12' X-band Antenna
- 0.05 0.9
30 KW Transceiver
12' S-band Antenna
- - 0.4
X-Ray radiation
This radar system does not generate X-ray radiation.
