ADF Pressure Plate

1. Lift ADF assembly up.

2. Use flat-head driver on (A) part and remove ADF pressure plate.

Be careful not to lose pinch pad spring.

ADF’s Document Tray Assembly

1. Remove ADF’s top cover.

2. Remove ADF Pick up Assembly

3. Remove ADF idle guide.
