Sindoh M400 - Control Panel; Scan Cover Assembly

To Next Page

To Previous Page

Control Panel

1. Unlock 4 hooks at the bottom of front scanner cover and lift the Control Panel up.

2. Remove Control Panel’s harness.

Scan Cover Assembly

1. Remove ADF assembly.

2. Remove Control Panel.

3. Unlock 3 hooks on scanner’s back.
