When this message appears, printing can continue, but for 2.5K, the Toner END occurs with 5% chart as
base to have no more printouts and it needs to be replaced with a new toner cartridge. And also, toners
for 2.5K/5K/8K will have Toner END occurrences when continue to make printouts after Toner Low to
unable to use.
The printer is installed with a 250 sheets of A4/LT cassette Tray with 75gsm as base and a bypass tray as
the base and 250 sheets feeding unit can be added optionally.
A friction pad method is used as paper separating method for main tray and a paper detecting sensor is
mounted to determine paper presence, but a separate auto paper size detecting sensor is not installed,
which allows the printer to detect the paper size by on-off timing of Registration sensor.
When loading papers to main tray, adjust the side fences and rear fence to not to have gaps in the
cassette.
For thick papers (28lb, 105g/m
2
) and special papers, there is a load limit line indication.
Main Tray Components and Feeding and Isolating Mechanism
Main Tray is composed with the following 6 components and rolls of each component are as the
followings.
1) Base Plate: It is in the cassette tray loading papers and applies appropriate pressure between
roller and paper by picking the paper loaded in the tray with main body’s pickup roller.
2) Left and Right Side Fences: Aligns the loaded papers to its size.
3) Rear Fence: Aligns the rear side of loaded papers to its size.
Move the rear fence lever to adjust.
4) Rear Fence Expanding Lever: Use it to expand the rear fence when loading legal papers.
5) Isolation Friction Pad Assy: Isolates the papers fed from the tray one by one
6) Base Plate Pad: It holds the bottom paper to allow papers not to be fed more than 2 when
there’s small amount of papers in the tray.
