- LED for 3-in-1

5. Buzzer controller

Pin Array

1. UICC- SYSTEMCARD (CN1)

NO.

Signal

Description

+5V

5V input power

COM1

GND

Data signal to systemcard

Data signal from systemcard

COM1

GND

WAKEUP_LED

Wakeup LED power

WAKEUP_BTN

Power save disable signal
