Image Fusing

Overview

Fusing Unit Components

Fusing Unit and paper discharge unit are composed with following components.

1. Fuser Roller

2. Pressure Roller

3. Heater

4. THERMOSTAT

5. THERMISTOR

6. Separator

7. Entrance Guide

8. Exit Guide

9. Exit Sensor

10. IDLE Roller

11. Cleaning Roller
