Sindoh M400 - Systemcard-Atii Cis (Cn4); Systemcard-Bldc_Motor (Cn41)

9
COM2
Analog ground
10
CIS_VREF
CIS VREF power input signal
11
CIS_MODE
CIS MODE selection signal
12
VOUT
CIS output signal
3. SYSTEMCARD-ATII CIS (CN4)
NO.
Signal
Description
1
COM1
GND
2
CIS_RED
For RED_LED Operation – Current Signal
3
CIS_GREEN
For GREEN_LED Operation – Current Signal
4
CIS_BLUE
For BLUE_LED Operation – Current Signal
5
CIS_LED_Anode
For LED Operation + Current Signal
6
CIS_CLK
Image data output synchronization clock
7
CIS_SP
Line unit control signal on CIS data output
8
CIS_VREF
CIS VREF power input signal
9
+3.3VAS
CIS_VCC
10
COM2
Analog ground
11
CIS_MODE
CIS MODE selection signal
12
VOUT
CIS output signal
4. SYSTEMCARD-BLDC_MOTOR (CN41)
NO.
Signal
Description
1
S.GND
SIGNAL GND
2
BLDC_FG
F/B signal to confirm motor rotation standard
3
BLDC_CLK
Standard clock supplied to motor
4
BLDC_ST
Motor ON signal
5
BLDC_LD
Configured RPM reception detection
6
P.GND
POWER GND
7
24V
+24V power
8
3.3V
+3.3V power
9
CW_nCCW
Rotation Direction Setting Signal
