Sindoh M400 - Page 84

CH1
CH2
Heater
Voltage (V)
+5.0Vdc
+24.5Vdc
110V
Voltage
Range
Static Mutual Load
Variation
and dynamic load
variation
+4.75V~+5.25V
(-5%~+5%)
+21.44V~+27.56V
(-12.5%~+12.5%)
Average Load
Same as above
+22.78V~+26.22V
(-7.0%~+7.0%)
Output
Load
Condition
Cover Open
0.25A
0.025A
-
Energy Saver
0.1A
0.05A
-
Minimum Output
Current
0.25A
0.05A
-
Nominal Output
Current
1.2A
2.3A
-
Maximum Output
Current
2.0A(maintain
operation for
minimum of 30
min.)
2.8A(maintain
operation for minimum
of 30 min.))
-
Peek Output
Current
-
5.4A
-
2
nd
Rush Current
(Surge Current)
20A
(Min. of 50uS)
Total Max. Output
Power
10.0W
68.6W
750W
Static Mutual
Load Variation
Condition
5V min – 24V max
5V max – 24V min
Ripple and Noise Voltage
100mVp-p
300mVp-p
-
Over Voltage
Within voltage
range
Within voltage range
-
Over
Current
Protection
Over current limit
Fuse
6A ~ 10A
-
Restoration
Method
Fuse Exchange
AC Reset
-
Short circuit
protection
operation
Power Isolation
Power Isolation
-
Over
Voltage
Protection
Over voltage limit
7V
30V
-
Restoration
Method
AC Reset
AC Reset
-
* (1) Channels: 2 channels with 5V and 24V
(2) Operate power isolation mode on OCP, OVP and other protect activations
