© Mar. 2023 82 AB16EJ Plus Maintenance Manual
ELECTRICAL SYSTEM
Table 8-5 General fault codes of motor controller (Continued)
Fault
code
Description
Cause Solution
the motor if necessary.
Note: The pins #7 and #8 of the 35-pin
controller connector are for motor temperature
sensor.
0328
Reduced overheat
performance of RL motor
controller
0428
Reduced overheat
performance of RR motor
controller
0029
Temperature sensor fault of
pump motor controller
1. Motor temperature
sensor fault;
2. Motor temperature
sensor type setup
error.
1. Check the wiring of motor temperature
sensor;
2. Check the setup of motor temperature sen-
sor (programme/motor menu/temperature
control sensor type).
3. Replace the motor temperature sensor.
Note: The pins #7 and #8 of the 35-pin
controller connector are for motor temperature
sensor.
0129
Temperature sensor fault of
FL motor controller
0229
Temperature sensor fault of
FR motor controller
0329
Temperature sensor fault of
RL motor controller
0429
Temperature sensor fault of
RR motor controller
0031
Open/short-circuited driver 1
output/main contactor of
pump motor controller
1. Driver 1 wiring fault;
2. Loading device fault;
3. Contactor fault.
1. Check if the wiring is correct and pins are
stained or damaged;
2. Monitor output signal (monitor menu/out-
puts menu/Driver 1 PWM) to check
whether there is output control signal;
3. Check the coil of contactor;
4. Replace the contactor.
Note: The pin #6 of the 35-pin controller
connector is for driver 1 output.
0131
Open/short-circuited driver 1
output/main contactor of FL
motor controller
0231
Open/short-circuited driver 1
output/main contactor of FR
motor controller
0331
Open/short-circuited driver 1
output/main contactor of RL
motor controller
0431
Open/short-circuited driver 1
output/main contactor of RR
motor controller
0032
Open/short-circuited driver 2
of pump motor controller
1. Driver 2 wiring fault;
2. Loading device fault;
3. Contactor fault.
1. Check if the wiring is correct and pins are
stained or damaged;
2. Monitor output signal (monitor menu/out-
puts menu/Driver 2PWM) to check
whether there is output control signal;
3. Check the coil of contactor;
4. Replace the contactor.
Note: The pin #5 of the 35-pin controller
connector is for driver 2 output.
0132
Open/short-circuited driver 2
of FL motor controller
0232
Open/short-circuited driver 2
of FR motor controller
0332
Open/short-circuited driver 2
of RL motor controller
0432
Open/short-circuited driver 2
of RR motor controller
0033
Open/short-circuited
solenoid brake/coil 3 output
of pump motor controller
1. Open/short circuited
coil of solenoid brake;
2. Stained/damaged/bro-
ken wiring.
1. Check if the wiring is correct and pins are
stained or damaged;
2. Monitor output signal (monitor menu/out-
puts menu/Driver 3 PWM) to check
whether there is output control signal;
0133
Open/short-circuited
solenoid brake/coil 3 output
of FL motor controller
