Table 8-5 General fault codes of motor controller (Continued)
Fault
code
Description
Cause Solution
3. Check the coil of contactor;
4. Replace the solenoid brake.
Note: The pin #4 of the 35-pin controller
connector is for driver 3 output.
0233
Open/short-circuited
solenoid brake/coil 3 output
of FR motor controller
0333
Open/short-circuited
solenoid brake/coil 3 output
of RL motor controller
0433
Open/short-circuited
solenoid brake/coil 3 output
of RR motor controller
0034
Open/short-circuited coil 4
output of pump motor
controller
1. Open/short-circuited
coil 4;
2. Stained/damaged/bro-
ken wiring.
1. Check if the wiring is correct and pins are
stained or damaged;
2. Monitor output signal (monitor menu/out-
puts menu/Driver 4PWM) to check
whether there is output control signal;
3. Check the driver coil.
0134
Open/short-circuited coil 4
output of FL motor controller
0234
Open/short-circuited coil 4
output of FR motor controller
0334
Open/short-circuited coil 4
output of RL motor controller
0434
Open/short-circuited coil 4
output of RR motor
controller
0035
Proportional drive error of
pump motor controller
1. Open/short-circuited
loading device;
2. Stained/damaged/bro-
ken wiring;
3. Improper wiring.
1. Check if the wiring is correct and pins are
stained or damaged;
2. Monitor output signal “monitor menu/out-
puts menu/PD PWM” to check whether
there is output control signal;
3. Check the loading devices, such as the
driver coil, for damage.
0135
Proportional drive error of
FL motor controller
0235
Proportional drive error of
FR motor controller
0335
Proportional drive error of
RL motor controller
0435
Proportional drive error of
RR motor controller
0036
Encoder error of pump
motor controller
1. Failed power supply of
encoder;
2. Damaged encoder;
3. Improper wiring.
1. Check the encoder power supply;
2. Check the pulse count of encoder setup
(programme/motor menu/encoder steps);
3. Check the encoder feedback speed sig-
nals (monitor/motor menu/motor speed A/
B);
4. If the inspections above fail to discover the
problem, replace the motor.
Note: The pins #31 and #32 of the 35-pin
controller connector are for encoder AB phase
output signals.
0136
Encoder error of FL motor
controller
0236
Encoder error of FR motor
controller
0336
Encoder error of RL motor
controller
0436
Encoder error of RR motor
controller
0037
Open-circuited pump motor
controller
1. Missing phase in
motor;
2. Improper wiring;
1. Ensure the UVW 3-phase wiring not open-
circuited;
2. Use a multimeter to check the UVW power
0137
Open-circuited FL motor
controller
