TB20J Plus Maintenance Manual 139
© Feb. 2023
11 CONTROL SYSTEM
All operations in this section must be performed
by qualified personnel who have been
professionally trained and authorized by
Sinoboom, otherwise the consequences will be at
your own risk.
Unsafe Operation Hazard
• The machine has been commis-
sioned before delivery. It’s forbid-
den to modify the system settings
and update the program without
authorization from Sinoboom.
Due to different machine configu-
rations, certain descriptions be-
low may be inapplicable to your
machine. In case of any opera-
tional questions when operating
the machine as per the manual,
please stop operation and contact
Sinoboom after-sales personnel
in time.
• Incorrect operation may result in
death, serious injury or machine
damage.
NOTICE
PCU, ECU, sensors, etc. are precisely adjusted and
protectively treated before delivery. Therefore,
personnel who have not been professionally trained
and authorized by Sinoboom cannot disassemble
their housings, otherwise moisture and dust will enter
the internal mechanism and normal operation will not
be guaranteed.
This section is applicable to Rexroth control system
equipped with the Rising display.
11.1 DISPLAY INTERFACE
The system interface is as shown in the figure below:
Note: some interfaces can only be accessed with a
password (the password can only be provided to per-
sonnel professionally trained and authorized by
Sinoboom).
