Sinoboom TB20J Plus - Main Interface after Booting; Description of Icon Functions

CONTROL SYSTEM
TB20J Plus Maintenance Manual 141
© Feb. 2023
11.2 MAIN INTERFACE AFTER
BOOTING
Turn the ground/platform selector switch on the ground
controller to the ground control position, pull out the
emergency stop button to the ON position, and turn the
key switch to the ON position, and the system will be
powered on.
Fig 2 Main interface after booting
11.3 DESCRIPTION OF ICON
FUNCTIONS
Table 11-1
Icon
Description
Icon
Description
Configuration Left/Right arrow key
Turntable panel information
Increase key
