Sintrones VBOX-3600 - LED JST Connector (LED2)

2.0 Internal Connector Specification
User’s Manual Page 2-7
2.7 LEDJSTConnector(LED2)
Connector
size
2 X 2 = 4 Pin
Connector
type
LED WITH HOUSING
Connector
location
LED2
Connector
pin
definition
Pin Signal Pin Signal
A1 ACC_LED
_
PA2HDD_LED
_
P
C1 ACC_LED
_
NC2HDD_LED
_
N
Connector
map
