Sintrones VBOX-3600 - Mini PCI-E Slot: (MiniCard1)

2.0 Internal Connector Specification
User’s Manual Page 2-14
2.14 MiniPCI‐ESlot:(MiniCard1)
Connector
size
2 X 26 = 52 Pin
Connector
type
MINI PCI-E CON 9.2mmH
Connector
location
MINICARD1
Connector
pin
definition
Pin Signal Pin Signal
1 PCIE_WAKE# 2 3VSB
3 NC 4 GND
5 NC 6 +1.5V
7 MINICARD1
_
CLKREQ# 8 UIM_PWR
9 GND 10 UIM_DAT
11 NC 12 UIM_CLK
13 NC 14 UIM_RST
15 GND 16 NC
17 NC 18 GND
19 NC 20 MINICARD1
_
DIS#
21 GND 22 PCIE_RST#
23 NC 24 3VSB
25 NC 26 GND
27 GND 28 +1.5V
29 GND 30 SMB_CLK
31 NC 32 SMB_DATA
33 NC 34 GND
35 GND 36 USB_4N
37 GND 38 USB_4P
39 3VSB 40 GND
41 3VSB 42 LED_WWAN#
43 GND 44 LED_WAN#
45 NC 46 LED_WPAN#
47 NC 48 +1.5V
49 NC 50 GND
51 NC 52 3VSB
