Sintrones VBOX-3600 - CAN BUS Pin Assignment

3.0 External Connector Specification
User’s Manual Page 3-15
3.15 CANBUSPinAssignment




A. Connectorpindefinition
Pin Signal Pin Signal
1 nc 6 CAN_GND
2 CAN_L 7 CAN_H
3 CAN_GND 8 nc
4 nc 9 nc
5 nc

