Sintrones VBOX-3600 - USB3.0 Type A Connector

3.0 External Connector Specification
User’s Manual Page 3-2
3.2 USB3.0TypeAConnector
Connector
size
8 Pin
Connector
type
USB3.0 Type A
Connector
location
USB4
Connector
pin
definition
Pin Signal Pin Signal
1 5VSB 2 USB2
_
N
3 USB2
_
P4GND
5 SSRX2
_
ON 6 SSRX2
_
OP
7 GND 8 SSTX20_ON
9 SSTX2
_
OP 10 5VSB
11 USB3
_
N12USB3
_
P
13 GND 14 SSRX3
_
ON
15 SSRX3
_
OP 16 GND
17 SSTX3
_
ON 18 SSTX3
_
OP
Connector
map
