Sintrones VBOX-3600 - COM Port JST Connector (COM3)

2.0 Internal Connector Specification
User’s Manual Page 2-8
2.8 COMPortJSTConnector(COM3)
Connector
size
2 X 5 = 10 Pin
Connector
type
JST-2.0mm-M-180
Connector
location
COM3
Connector
pin
definition
Pin Signal Pin Signal
1 COM3
_
DCD 2 COM3
_
RXD
3 COM3
_
TXD 4 COM3
_
DT
R
5 GND 6 COM3
_
DS
R
7 COM3
_
RTS 8 COM3
_
CTS
9 COM3
_
RI 10 GND
Connector
map
