5.0 System Resource
User’s Manual Page 5-4
GPIO5OutputDataRegister–IndexA1h
Bit Name R/W Default Description
7 GPIO57_DATA R/W 1 GPIO57outputdatainoutputmode.
6 GPIO56_DATA R/W 1 GPIO56outputdatainoutputmode.
5 GPIO55_DATA R/W 1 GPIO55outputdatainoutputmode.
4 GPIO54_DATA R/W 1 GPIO54outputdatainoutputmode.
3 GPIO53_DATA R/W 1 GPIO53outputdatainoutputmode.
2 GPIO52_DATA R/W 1 GPIO52outputdatainoutputmode.
1 GPIO51_DATA R/W 1 GPIO51outputdatainoutputmode.
0 GPIO50_DATA R/W 1 GPIO50outputdatainoutputmode.
GPIO5PinStatusRegister–IndexA2h
Bit Name R/W Default Description
7 GPIO57_ST R 1 GPIO57pinstatus.
6 GPIO56_ST R 1 GPIO56pinstatus.
5 GPIO55_ST R 1 GPIO55pinstatus.
4 GPIO54_ST R 1 GPIO54pinstatus.
3 GPIO53_ST R 1 GPIO53pinstatus.
2 GPIO52_ST R 1 GPIO52pinstatus.
1 GPIO51_ST R 1 GPIO51pinstatus.
0 GPIO50_ST R 1 GPIO50pinstatus.
