1.0 Introduction
User’s Manual Page 1-2
Graphics
Graphics
Intel®HDGraphics4000
DirectXVideoAcceleration(DXVA)forAcceleratingVideo
Processing‐FullAVC/VC1/MPEG2HWDecode
SupportsDirectX11/10.1/10/9andOpenGL3.0
Resolution Upto1920x1200
Qualification
Certifications CE,FCCClassA,E‐mark
I/O
SerialPort 4xRS‐232(COM1,2withRS‐485SupportAutoDirectionControl)
USBPort 4xUSB2.0PortsonFrontI/O
LAN 2xRJ45PortsforGbE
VideoPort 1xDVI‐I,1xVGAand1xDisplayPortOutput
DIOPort 4inand4outwithRelay12V/80mA
Audio 1xLine‐outand1xMIC‐in
SIMCardSocket 2xSIMCardsocketssupportedonboardwitheject
Environment
OperatingTemp.‐40ºC~70ºC(DefaultCPU17Watt)
StorageTemp.‐40~80ºC
RelativeHumidity 0%RH–95%RH
Vibration(random) 2.5g@5~500HzwithSSD
VibrationOperating MIL‐STD‐810F,Method514.5,Category20,GroundVehicle‐Highway
TruckStorage MIL‐STD‐810F,Method514.5,Category24,IntegrityTest
Shock
Operating:MIL‐STD‐810F,Method516.5,ProcedureI,
Trucksandsemi‐trailers=40G(11ms)withSSD
CrashHazard
MIL‐STD‐810F,Method516.5,ProcedureV,
Groundequipment=100
Mechanical
Construction Aluminumalloy
Mounting Supportsbothofwall‐mount/VESA‐mount
Weight 1.780kg(bare‐bone)
Dimensions 250x150x55mm
