SIPOS AKTORIK SIPOS 5 User Manual

Operation instructions
SIPOS 5 PROFITRON, HiMod
Page 26 Y070.020/GB
5 Commissioning
5
Commissioning
5.4.2 Programming output speeds/positioning speeds/positioning times
By programming the output speeds, the speed of the actuator during closing, opening and approa-
ching the EMERGENCY position is determined. Depending on the actuator type, different values for
the speed are programmed and indicated in the display:
The following parameters are possible:
Speeds in rpm for rotary actuator 2SA5
Speed ranges Possible values for output speed parameter
Standard actuator
1,25 – 10 1,25 1,75 2,5 3,5 5 7 10
2,5 – 20 2,5 3,5 5 7 10 14 20
5 – 28 5 7 10 14 20 28 ---
5 – 40 5 7 10 14 20 28 40
10 – 80 10 14 20 28 40 56 80
20 – 112 20 28 40 56 80 112 ---
20 – 160 20 28 40 56 80 112 160
Modulating actuator
1,25 – 10 1,25 1,75 2,5 3,5 5 7 10
5 – 40 5 7 10 14 20 28 40
Speed levels
Standard = 4
1234567
Positioning speeds mm/min for linear actuator 2SB5
Positioning speed ranges Possible values for positioning speed parameter
25 – 200 25 35 50 70 100 140 200
30 – 240 30 42 60 84 120 168 240
35 – 280 35 49 70 98 140 196 280
40 – 320 40 56 80 112 160 224 320
Positioning speed levels:
Standard = 4
1234 567
Positioning times in s/90° for part-turn actuators 2SC5 and 2SG5
Positioning time range Possible values for positioning time parameter
2SC5 160 – 20 160 112 80 56 40 28 20
2SG5 80 – 10 80 56 40 28 20 14 10
Positoning time levels:
Standard = 4
1234 567
Operation sequence
If the actuator is in the „commissioning“ menu, continue with operation step 2. For a detailed de-
scription of operation step 1, refer to chapter 5.3 „Access to the commissioning menu.“
1. Call up the main menu in the „locPar“ state, select
„commissioning“ menu and enter code 9044.
close direction
anti-clockwise
2. Use the
button to change to the speed parameter for
CLOSE direction. The indication in the display differs
depending on the type of actuator:
– „closing speed“ for rotary actuator,
– „Act. speed cl“ for linear actuator and
– ”Act. time cl“ for part-turn actuator.
closing speed
28 /min
3. Press ENTER to activate selection. The indication in
the second display line is blinking.
closing speed
28 /min
28 /min
