5Care, cleaning and maintenance by the practice team Sirona Dental Systems GmbH
5.4Vacuum system Operating Instructions INTEGO
3. Attach the open suction handpiece to the receptacle.
4. Press the button.
 Water is pumped into the suction hose cleaning container and
suctioned out of the suction hoses. The end of the suction hose
cleaning can be heard by the suction noise. If the Compact water
unit is equipped with an amalgam separator, a signal can be
heard at the end of the suction hose cleaning.
5. Then place the suction hose back into the holder on the assistant
element.
6. Repeat this procedure for the other suction handpieces.
Vacuum system, hose fittings
CAUTION
Suction hose cleaning must not be interrupted to ensure that no residual
water remains in the container.
CAUTION
Disinfect the hose fittings on the water unit after each patient.
