Sirona Intego Pro - CS Dentist Element with Swivel Arms

64 57 498 D3543
38 D3543.201.01.05.02 08.2016
3Unit description Sirona Dental Systems GmbH
3.9Dentist element Operating Instructions INTEGO
3.9.2 CS dentist element with swivel arms
On the CS dentist element, instruments are placed on the instrument
holder horizontally and facing downwards. The instrument hoses are
placed above the dentist element over the whip arms.
EasyTouch for INTEGO and I NTEGO pro
A Instrument holder (max. 5 instruments)
B Swiveling tray holder on the CS dentist element for one or two
(shown here) standard trays
C Removable handle covers (left/right)
D Button to release the support arm brake for adjusting height
(left/right)
E EasyPad or EasyTouch user interface (shown here)
F Holder with non-slip silicone mat
GX-ray viewer
H Swivel arms
I Support arm
B
A
G
D
E
C
H
F
I
