Sirona Intego Pro - Head Support; Flat Headrest; Double-Jointed Head Support

64 57 498 D3543
34 D3543.201.01.05.02 08.2016
3Unit description Sirona Dental Systems GmbH
3.7Head support Operating Instructions INTEGO
3.7
Head support
3.7.1 Flat headrest
The headrest extension can be pulled in or out depending on the patient's
height. For upper jaw treatment, the magnetic head pad can be rotated
and used as a neck rest.
For details, see "Adjusting the headrest" [ → 73].
3.7.2 Double-jointed head support
The double articulating headrest is equipped with two rotary joints. They
allow the head inclination to be manually adjusted over a wide range for
maxillary/mandibular treatment. The headrest extension can be pushed
in or pulled out to manually adjust it to the height of the patient.
For details, see "Adjusting the double articulating headrest." [ → 73]
A Removable magnetic head pad
B Handle for adjusting height
A
B
A Head pad
BRotary joints
C Unlock button (one-sided)
D Support bar for adjustment to patient height
