Sirona Intego Pro - Ambidextrous Water Unit

64 57 498 D3543
D3543.201.01.05.02 08.2016
55
Sirona Dental Systems GmbH 3Unit description
Operating Instructions INTEGO 3.11Water unit
båÖäáëÜ
3.11.3 Ambidextrous water unit
A Manually swiveling cuspidor (removable)
B Tumbler filler
C Cover of the storage tank for disinfectant or stand-alone water
supply (only with the INTEGO pro)
D Cleaning adaptor for water-carrying instruments of the dentist
element for sanitizing and auto purge.
E Maintenance flap for accessing the cleaning agent tank to
chemically clean the suction hoses, the flushing valve, the filter
cartridge for standard wet suction
The amalgam separator and sediment container are removed
from underneath with the Ambidextrous water unit.
F Cleaning adapter for the SPRAYVIT E and for a suction hose of
the assistant element
G Fresh water bottle (only with the INTEGO)
H Foot pedal for unlocking the water unit
I Suction hose connection to the Comfort assistant element
