Reshipment procedure
If the probe system and/or accessories must be reshipped,
use the original shipping container and packing materials.
If the original packing materials are not available, the
following materials are recommended.
At least 2” (50 mm) of shock absorbing material such as •
ester foam or any other material designed to absorb light
to medium shock loads.
The package should provide protection for “normal” •
handling. For example, a 3 feet (1 meter) vertical drop.
Returned equipment with warranty or damage claims
If the probe system or accessories are damaged in transit
or do not operate as specified when received, notify the
carrier and the nearest SKF Condition Monitoring, Inc.
sales/service office or SKF representative immediately.
Telephone 1-800-523-7514 or 1-858-496-3627. Email
address comoRA-USA@skf.com.
The local office will arrange for repair or replacement. SKF
Condition Monitoring, Inc. will assign a Return Material
Authorization (RMA) number to assure identification and
tracking of your equipment.
Selecting an eddy probe system
A wide variety of SKF systems are offered to meet the
requirements of virtually any application. Probe range is
limited largely by the probe’s diameter. The standard SKF
probe diameters are 5 mm (CMSS 65), 8 mm (CMSS 68),
and 19 mm (CMSS 62).
The following should be considered when selecting a
system:
Range
Gap over which the system must accurately operate.
Sensitivity
Must be compatible with monitors or other companion
instruments.
System length
The physical length of the systems is approximate to the
electrical length. Excess cable in certain installations is
typically coiled and tied with no harmful effects.
Probe case
The size of the probe mounting case may be a factor in
some installations.
Section 1 – General information
1-3
Table 1-4. Standard SKF Eddy Probe Systems.
System Usable range Sensitivity System length Standard case Comments
CMSS 60/CMSS 600
CMSS 60/CMSS 600-1
90 mils
90 mils
200 mV/Mil
200 mV/Mil
5 meters
10 meters
3/8-24
3/8-24
Standard length
Long system length
CMSS 61/CMSS 606
CMSS 61/CMSS 627
80 mils
80 mils
200 mV/Mil
200 mV/Mil
5 meters
9 meters
1/4-28
1/4-28
Standard length
Long system length
CMSS 62/CMSS 620-2 60-300 mils 50 mV/Mil 10.8 meters 1”-12 UNF Long range
CMSS 65/CMSS 665
CMSS 65/CMSS 665-1
CMSS 65/CMSS 665-16-9
CMSS 65/CMSS 665-20-00
80 mils
80 mils
45 mils
80 mils
200 mV/Mil
200 mV/Mil
200 mV/Mil
200 mV/Mil
5 meters
10 meters
5 meters
5 meters
1/4-28
1/4-28
1/4-28
1/4-28
Standard length
Long system length
Intrinsically safe
Non-incentive
CMSS 68/CMSS 668
CMSS 68/CMSS 668-1
CMSS 68/CMSS 668-2
CMSS 68/CMSS 668-16-9
CMSS 68/CMSS 668-20-00
90 mils
90 mils
90 mils
65 mils
90 mils
200 mV/Mil
200 mV/Mil
200 mV/Mil
200 mV/Mil
200 mV/Mil
5 meters
10 meters
15 meters
5 meters
5 meters
3/8-24
3/8-24
3/8-24
3/8-24
3/8-24
Standard length
Long system length
Long system length
Intrinsically safe
Non-incentive
