EN
14. Spare parts
14.6 SSVM metering devices
Standard version, black galvanized
Designation Q ty. Part number
SSVM 6 1 619-26761-1
SSVM 8 1 619-37044-1
SSVM10 1 619-26846-1
SSVM12 1 619-37049-1
with indicator pin, black galvanized
Designation Q ty. Part number
SSVM 6-K 1 619-26762-3
SSVM 8-K 1 619-37045-3
SSVM 10-K 1 619-26847-2
SSVM 12-K 1 619-37050-3
14.7 SSVD-E metering devices
Standard version, black galvanized
Designation Q ty. Part number
SSVD 6-E 1 649-77394-1
SSVD 8-E 1 649-77395-1
SSVD10-E 1 649-77396-1
SSVD12-E 1 649-77397-1
SSVD14-E 1 649-77398-1
SSVD16-E 1 649-77399-1
SSVD18-E 1 649-77400-1
SSVD20-E 1 649-77401-1
SSVD22-E 1 649-77402-1
14.8 Metering screws for SSVD, SSVD-E
Coding
Length
[mm]
Metered volume
[cm
3
/stroke]
Qty. Part number
8/A 46.7 0.08 12 549-34254-1
14/B 45.9 0.14 12 549-34254-2
20/C 44.7 0.20 12 549-34254-3
30/D 42.7 0.30 12 549-34254-4
40/E 40.7 0.40 12 549-34254-5
60/F 36.7 0.60 12 549-34254-6
80/G 32.7 0.80 12 549-34254-7
100/H 28.7 1.00 12 549-34254-8
140/I 20.8 1.40 12 549-34254-9
180/y 12.8 1.80 12 549-34255-1
Set of resp. 2 metering screws of all sizes 20 549-34255-2
Set of resp. 2 metering screws of all sizes
in VA 1.4571
20 549-34255-3
- 72 -
951-171-049
Version 02
