EN
14. Spare parts
14
14.9 Outlet cap screws
Designation Qty. Part number
Outlet cap screw with sealing edge for SSV, SSV-E, SSVD, SSVD-E 1 303-17499-3
Outlet cap screw with sealing edge for SSVM 1 303-16284-1
14.10 Mounting bracket SSV
Designation Qty. Part number
Mounting bracket SSV and SSV-E as of size 14 1 519-34271-1
Mounting brackets SSVD and SSVD-E as of size 12 1 549-34269-1
Delivery including fastening material
14.11
Designation Qty. Part number
Push-in type fitting RV -6-M10x1-S01 Multi Pressure (tube Ø 6 mm) 1 226-14091-4
Push-in type fitting RV 6511 -4-M8x1-S02 for SSVM (tube Ø 4 mm) 1 226-14091-5
Screw-in fitting for SSV, SSV-E, SSVD (tube Ø 6 mm) 1 504-30344-4
Screw-in fitting for SSVM with check valve (tube Ø 4
mm)
1 519-31661-1
14.12
Designation Qty. Part number
Hydraulic lubrication fitting B R 1/8 Z 1 251-14045-1
- 73 -
951-171-049
Version 02
