Replacement Procedures
Service Manual
SKOPE Reflex Underbench Fridge and Freezer
CAUTION
Some connector colours vary depending on date of manufacture.
After unplugging connectors, ALWAYS ensure reconnection has
been undertaken correctly as operational faults may occur if
incorrect. SKOPE recommends photographing the wiring setup for
future reference before unplugging.
Procedure 15: To remove the refrigeration cartridge
Before you start
If a customer reports a “not cooling” fault, and it has been established that the cabinet is not cooling,
follow the “On-site Work Procedure” on page 48 when making the service visit.
1. Unplug the cabinet from the power supply, and cut the cable tie at the back of the cabinet to
release the power cord.
2. Unscrew the front panel (Phillips head screwdriver):
• two screws at the bottom of the front cover
• two screws at the top of the front cover
3. Unscrew the cartridge (Allen key):
• two screws at the bottom of the cartridge
• four screws on the right hand side of the cartridge
4. Partially slide the cartridge out.
• Use the handles at the front of the cartridge, and take care of loose plugs, cables and the
evaporator box gasket when sliding the cartridge.
• Release the electrical cables on the left hand side of the cartridge by cutting the cable ties
securing the cables.
5. Photograph wiring setup for future reference when refitting the cartridge.
6. Unplug the cartridge from the cabinet (see “6. Electrics panel and loom electrical connections.” on
page 35):
• Black 3-way plugs (heater wire cartridge sockets).
• White 2-way plug (door sensor socket/plug)
• Red 2-way plug (cabinet lighting plugs)
• White 6-way plug (cartridge junction box to controller signal socket/plug)
• Black 4-way plug (cartridge to controller power socket)
• Orange 4-way plug (cartridge to controller power socket 1)
• Green 4-way plug (LED lighting loom socket/plug)
