33
SKOPE Reflex Underbench Fridge and Freezer
Replacement Procedures
Service Manual
7. The cartridge can now be removed from the cabinet.
8. When swapping cartridge, detach the electrics panel and electronic controller from the cartridge.
• To remove the electrics panel, unscrew the five screws (Phillips head screwdriver) around the
perimeter of the panel.
• To remove the controller, press and hold the tabs on each side of the electronic controller to
unlock, and push the controller through the front of the controller box. Unplug the electronic
controller from the cartridge.
9. Reverse the steps above to refit the cartridge. When refitting, ensure that:
• the evaporator box gasket is in good condition.
• all plugs and cables are re-connected to the correct socket and cable-tied back into place.
• wires and cables are clear of the cartridge when moving it.
• the cartridge is pushed fully in the cabinet and screwed in place.
Ensure the tabs on the back of the cartridge are located in the slots at the back of the cabinet.
• the front cover is refitted.
IMPORTANT: Ensure that you reconnect the plugs correctly, as operational faults may occur
otherwise. Refer to the relevant image on page 35, wiring diagram on page 10, and recommended
photograph for reference.
Procedure 15: To remove the refrigeration cartridge (continued)
