Skyjack SJ20 Service Manual

63
SJ20 238886ABA
Section 5 – ProceduresDisplay Module
Display Message Description Display Message Description
M145-TILT_ERR NO TILT SENSOR MESSAGE
M147-SERV_MODE FACTORY OVERRIDE
M151-KSW_ERR THE PLATFORM AND BASE ARE ACTIVE
M152-ENABLE_ERR REQUESTED FACILITATOR CYCLE
M153-M2_ERR_XX XX ENCODER ERROR
M154-M2_ERR_XX POWER NOT PAIRED XX
M155-M2_ERR_XX SPEED NOT MATCHED XX
M156-S10_ERR BASIC MODE + FUNCTION COMMAND
M157-M2_ERR_XX VOLTAGE NOT MATCHED
M158-CTRL_ERR NOT READY CONTROL DRIVER POWER
M159-CTRL_ERR HVIL FAIL
M160-TILTED MACHINE TILTED
M-163-M2_ERR ED SLIP NOT MATCHED
M169-M2_ERR_XX ENCODER ERROR XX
M170-CTRL_ERR INCORRECT KEY voltage
M175-M2_ERR SPEED SENSOR ERROR
M177-BRK1_ERR SHORT CIRCUIT COIL BRAKE
M178-M2_TEMP STOP MOTOR TEMP
M180-M2_ERR OVERLOAD
M181-M2_ERR INCORRECT ENCODER
M186-M2_ERR WAIT FOR MOTOR POSITION
M187-CTRL_ERR LIFTING + LOWERING
M188-CTRL_ERR INTERNAL CAN BUS ERROR
M189-SEQUENCE INCORRECT PUMP STARTING
M190-CTRL_ERR PUMP RETURN VOLTAGE NOT GOOD
M191-A1_ERR
THE TENSION CONTROL LEVER NOT
GOOD
M192-A1_ERR
THE CONTROL LEVER ACQUISITION NOT
GOOD
M193-CTRL_ERR FAULTY SMARTDRIVE
M194-CTRL_ERR AUXILIARY BATTERY SHORT CIRCUIT
M195-BRK1_ERR SHORT CIRCUIT POSITIVE COIL BRAKE
M196-M1_ERR SHORT CIRCUIT MOTOR PHASE
M197-CTRL_ERR SECONDARY INCORRECT VERSION
M198-CTRL_ERR
MAIN / SECONDARY INCORRECT CHECK
PARAMETER
M199-CTRL_ERR PARAMETER TRANSFER
M200-CTRL_ERR VDC OFF SHORT CIRCUIT
M201-M1_ERR TORQUE PROFILE
M202-CTRL_ERR HIGH VOLTAGE VDC LINK
M204-BRK1_ERR FAULTY SERVICE BRAKE
M206-CTRL_ERR INTERNAL VOLTAGE TOO HIGH
M207-CTRL_ERR INTERNAL VOLTAGE TOO LOW
M208-CTRL_ERR FAULTY EEPROM
M209-CTRL_ERR RESTORE PARAMETER
M210-CTRL_ERR INCORRECT RAM MEMORY
M211-M2_ERR STALL ROTOR
M212-M2_ERR POWER NOT PAIRED
M213-C1_ERR LC POSITIVE COIL OPEN
M214-2H-13_ERR OPEN COIL EVP
M215-2H-13_ERR SHORT-CIRCUIT CONTROL PILOT EVP
M216-BRK1_ERR OPEN COIL BRAKE
M217-CB2_PWR INCORRECT PEB
M218-M1_TEMP ENGINE SENSOR TEMP DEFECTIVE
M219-2H-13_ERR EVP1 POISITVE COIL INCORRECT
M220-08C_LOW VKEY OFF SHORT CIRCUITY
M223-C1_ERR MC SHORT CIRCUIT COIL
M224-CHK_
SECONDARY
WAITING FOR NODE
M226-JSTK_ERR DEFECTIVE VACC
M227-CTRL_ERR FAULT MATERIAL
M229-CTRL_ERR FAULT MATERIAL BRAKE
M230-C1_ERR LC OPEN COIL
M231-CTRL_ERR CURRENT PUMP NOT ZERO
M232-CTRL_ERRXX EV XX COMMON PILOT
M233-CTRL_ERR SHORT CIRCUIT POWER MOSFET
M234-CTRL_ERR EV SHORT-CIRCUIT
M235-CTRL_ERR CTRAP THRESHOLD
M236-CTRL_ERR CURRENT GAIN
