Skyjack SJ20 Service Manual

64
SJ20238886ABA
Section 5 – Procedures Display Module
Display Message Description Display Message Description
M238-CTRL_ERR EV FAULT MATERIAL
M239-CTRL_ERR FAULTY CONTROLLERS
M240-CTRL_ERR OPEN CONTROL PILOT EVP
M241-COIL_ERRXX SHORT CIRCUIT COIL EVAUX
M242-COIL_ERRXX EV OPEN COIL
M244-CHK_
SECONDARY
SECONDARY FAULT
M245-CTRL_ERR IQ NOT MATCHED
M246-CTRL_ERR OPEN CONTROL PILOT COIL BRAKE
M248-CAN_ERRXX NOT CAN MESSAGE
M249-CTRL_ERR VERIFICATION NECESSARY
M250-M2_TEMP TEMP SENSOR FAULT
M251-CTRL_ERR INCORRECT BATTERY
M253-CTRL_ERR FAULT FIELD ORIENTED CONTROL
M254-CTRL_ERR
SHORT CIRCUIT CONTROL PILOT COIL
BRAKE
S8-CTRL_ERR CONTROLLER ERROR
S17-CTRL_ERR LOGIC FAILURE #3
S18-CTRL_ERR LOGIC FAILURE #2
S19-CTRL_ERR LOGIC FAILURE #1
S28-M3_VLOW LOW Feedback VOLTAGE PUMP
S28-M3_VHI HIGH Feedback VOLTAGE PUMP
S28-DRV_VLOW LOW RETURN VOLTAGE
S28-DRV_VHI HIGH RETURN VOLTAGE
S37-C1 CLOSE CONTACTOR CLOSED
S38-C1 OPEN CONTACTOR OPEN
S52-M3_AMP_LOW PUMP I = 0 ALL THE TIME
S53-M3_AMP_HI HIGH STANDBY CURRENT
S60-CTRL_ERR CAPACITOR CHARGER
S62-CTRL_TEMP THERMAL PROTECTION
S65-M3_TEMP MOTOR TEMPERATURE
S66-LOW_BATT LOW BATTERY
S74-CTRL_ERR DRIVER SHORT CIRCUIT
S75-CTRL_ERR CONTACTOR DRIVER FAULTY
S78-JSTK_VERR ACCELERATOR VOLTAGE NOT OK
S79-ENABLE_ERR INCORRECT START-UP
S80-JSTK_ERR FORWARD + BACKWARD
S127-LOADC_ERR LOAD CELL NO MESSAGE XX
S128-LOADC_ERR LOAD CELLS SIGNAL NOT PAIRED
S129-JSTK_ERR JOYSTICK SAFTEY
S130-BRK2_ERR RELEASING THE BRAKES
S131-AO_ON ACTIVE ANTI-LIFT
S132-AO_ERR CHECK ANTI-LIFT
S133-TELEMATIC TELEMATICS STOP
S134-LOW_BATT LOW BATTERY VOLTAGE - DRIVE LOCKED
S135-OVER_TILT TILT DRIVE LOCKED
S136-LOAD_ERR FAULTY LOAD CELL
S137-OVERLOADED THE PLATFORM OVERLOAD
S138-SERVICE SERVICE MODE
S139-PL_EXT THE DEPLOYED PLATFORM
S140-LOW_BATT LOW BATTERY VOLTAGE - LIFT LOCKED
S141-TILT_ERXX XX TILT SENSOR ERROR
S142-CHARGING IN CHARGE
S144-CTRL_ERR INTERNAL BUS ERROR
S145-TILT_ERR NO TILT SENSOR MESSAGE
S147-SERV_MODE FACTORY OVERRIDE
S151-KSW_ERR THE PLATFORM AND BASE ARE ACTIVE
S152-ENABLE_ERR REQUESTED FACILITATOR CYCLE
S153-M3_ERR_XX XX ENCODER ERROR
S154-M3_ERR_XX POWER NOT PAIRED XX
S155-M3_ERR_XX SPEED NOT MATCHED XX
S156-S10_ERR BASIC MODE + FUNCTION COMMAND
S157-M3_ERR_XX VOLTAGE NOT MATCHED
S158-CTRL_ERR NOT READY CONTROL DRIVER POWER
S159-CTRL_ERR HVIL FAIL
S160-TILTED MACHINE TILTED
S161-M3_ERR HIGH RPM
S163-M3_ERR ED SLIP NOT MATCHED
S169-M3_ERR_XX ENCODER ERROR XX
