Skyjack SJ20 Service Manual

65
SJ20 238886ABA
Section 5 – ProceduresDisplay Module
Display Message Description Display Message Description
S170-CTRL_ERR INCORRECT KEY voltage
S175-M3_ERR SPEED SENSOR ERROR
S177-BRK2_ERR SHORT CIRCUIT COIL BRAKE
S178-M3_TEMP STOP MOTOR TEMP
S180-M3_ERR OVERLOAD
S181-M3_ERR INCORRECT ENCODER
S186-M3_ERR WAIT FOR MOTOR POSITION
S187-CTRL_ERR LIFTING + LOWERING
S188-CTRL_ERR INTERNAL CAN BUS ERROR
S189-SEQUENCE INCORRECT PUMP STARTING
S190-M1_ERR PUMP FEEDBACK VOLTAGE NOT GOOD
S191-JSTK_ERR CONTROL LEVER VOLTAGE NOT GOOD
S192-JSTK_ERR
THE CONTROL LEVER ACQUISITION NOT
GOOD
S193-CTRL_ERR FAULTY SMARTDRIVE
S194-CTRL_ERR AUXILIARY BATTERY SHORT CIRCUIT
S195-BRK2_ERR SHORT CIRCUIT POSITIVE COIL BRAKE
S196-M3_ERR SHORT CIRCUIT MOTOR PHASE
S97-CTRL_ERR SECONDARY INCORRECT VERSION
S198-CTRL_ERR
MAIN / SECONDARY INCORRECT CHECK
PARAMETER
S199-CTRL_ERR PARAMETER TRANSFER
S200-CTRL_ERR VDC OFF SHORT CIRCUIT
S201-M3_ERR TORQUE PROFILE
S202-CTRL_ERR HIGH VOLTAGE VDC LINK
S204-BRK2_ERR FAULTY SERVICE BRAKE
S206-CTRL_ERR INTERNAL VOLTAGE TOO HIGH
S207-CTRL_ERR INTERNAL VOLTAGE TOO LOW
S208-CTRL_ERR FAULTY EEPROM
S209-CTRL_ERR RESTORE PARAMETER
S10-CTRL_ERR INCORRECT RAM MEMORY
S211-M3_ERR STALL ROTOR
S212-M3_ERR POWER NOT PAIRED
S213-C1_ERR LC POSITIVE COIL OPEN
S214-2H-13_ERR OPEN COIL EVP
S215-2H-13_ERR SHORT-CIRCUIT CONTROL DRIVER EVP
S216-BRK2_ERR OPEN COIL BRAKE
S217-CB2_PWR INCORRECT PEB
S218-M3_TEMP ENGINE SENSOR TEMP DEFECTIVE
S219-2H-13_ERR EVP1 POISITVE COIL INCORRECT
S220-08C_LOW VKEY OFF SHORT CIRCUITY
S223-C1_ERR MC SHORT CIRCUIT COIL
S224-CHK_
SECONDARY
WAITING FOR NODE
S226-JSTK_ERR DEFECTIVE VACC
S227-CTRL_ERR FAULT MATERIAL
S29-CTRL_ERR FAULT MATERIAL BRAKE
S230-C1_ERR LC OPEN COIL
S231-CTRL_ERR CURRENT PUMP NOT ZERO
S232-CTRL_ERR ELECTRIC VALVE DRIVER
S233-CTRL_ERR SHORT CIRCUIT POWER MOSFET
S234-CTRL_ERR EV SHORT-CIRCUIT
S235-CTRL_ERR CTRAP THRESHOLD
S236-CTRL_ERR CURRENT GAIN
S38-CTRL_ERR EV FAULT MATERIAL
S239-CTRL_ERR FAULTY CONTROLLERS
S240-CTRL_ERR OPEN CONTROL PILOT EVP
S241-COIL_ERRXX SHORT CIRCUIT COIL EVAUX
S242-COIL_ERRXX EV OPEN COIL
S244-CHK_
SECONDARY
SECONDARY FAULT
S245-CTRL_ERR IQ NOT MATCHED
S246-CTRL_ERR OPEN CONTROL PILOT COIL BRAKE
S248-CAN_ERRXX NO CAN MESSAGE
S249-CTRL_ERR VERIFICATION NECESSARY
S50-M3_TEMP TEMP SENSOR FAULT
S251-CTRL_ERR INCORRECT BATTERY
S253-CTRL_ERR FAULT FIELD ORIENTED CONTROL
S254-CTRL_ERR
SHORT CIRCUIT CONTROL PILOT COIL
BRAKE
