Section 5 – ProceduresPlatform Removal
9. Use a suitably rated lifting device to pull out the
platform fully and set it aside on a protective
surface.
10. Remove the bolts and nuts that secure the lower
platform to the mast.
11. Make sure the load cells stay attached to the
mast.
12. Disconnect the connection from the junction box
to the mast cable.
