Skyjack SJ30ARJE User Manual

52
SJ30AJE, SJ30ARJE196274AF
Section 3 – System Component Identification and Schematics Electrical Parts List
Index
No.
Skyjack
Part No.
Qty. Description
4H-35 209028 1 COIL, 24 Volt (jib up) (SJ30AJE)
4H-35 208882 1 COIL, 12 Volt (jib up) (SJ30ARJE)
4H-36 209028 1 COIL, 24 Volt (platform left) (SJ30AJE)
4H-36 208882 1 COIL, 12 Volt (platform left) (SJ30ARJE)
4H-37 209028 1 COIL, 24 Volt (platform right) (SJ30AJE)
4H-37 208882 1 COIL, 12 Volt (platform right) (SJ30ARJE)
4H-38 208882 1 COIL, 12 Volt (fly boom retract)
4H-39 208882 1 COIL, 12 Volt (fly boom extend)
4H-40 208881 1 COIL, 12 Volt (platform level down)
4H-41 208881 1 COIL, 12 Volt (platform level up)
4H-42 208882 1 COIL, 12 Volt (jib rotate left)
4H-43 208882 1 COIL, 12 Volt (jib rotate right)
5H-32 208881 1 COIL, 12 Volt (turret rotate left)
5H-33 208881 1 COIL, 12 Volt (turret rotate right)
A1 138224 1 JOYSTICK, Drive/steer
A2 138225 1 JOYSTICK, Boom/turret
A3 138226 1 SWITCH, Speed control
BP1 144387 1 ALARM, Tilt
BP2 103057 1 ALARM, All motion
BP3 144387 1 ALARM, Overload
BP4 166110 1 BEEPER, SGE
CAP1 164511 1 CAPACITOR, 10 000 µF
CB1 137919 1 CIRCUIT BREAKER, 25 amp
CB2 137919 1 CIRCUIT BREAKER, 25 amp
DXX 102921 A/R DIODE
H 167234 1 HOURMETER
LB1 144078 1 LIGHT, Flashing
LB2 171888 1 LIGHT, Work
LB3 171888 1 LIGHT, Work
LB4 166110 1 BEACON, SGE
LS1 192758 1 LIMIT SWITCH, Direction sensing
LS2 192177 1 LIMIT SWITCH, Riser Down
LS3 192177 1 LIMIT SWITCH, Boom down
LS4 192178 1 LIMIT SWITCH, Fly in
PL2 147229 1 LIGHT, LED block (emergency stop)
PL3 164832 1 LIGHT, Pilot (tilt)
PL4 171501 1 LIGHT, Pilot (enable active)
PL5 164832 1 LIGHT, Pilot (overload)
PL6 171502 1 LIGHT, Pilot (low battery)
