SJ30AJE, SJ30ARJE 196274AF
Electrical Parts List Section 3 – System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Qty. Description
PL7 164832 1 LIGHT, Pilot (overload)
R1 151643 1 RESISTOR, 250 ohm
R2 151643 1 RESISTOR, 250 ohm
R3 151643 1 RESISTOR, 250 ohm
R4 151643 1 RESISTOR, 250 ohm
R5 151643 1 RESISTOR, 250 ohm
R6 151643 1 RESISTOR, 250 ohm
R7 151643 1 RESISTOR, 250 ohm
R8 151643 1 RESISTOR, 250 ohm
R9 151643 1 RESISTOR, 250 ohm
R10 151643 1 RESISTOR, 250 ohm
R11 151643 1 RESISTOR, 250 ohm
R12 151643 1 RESISTOR, 250 ohm
R13 144492 1 RESISTOR, 680 ohm
S2 144647 1 SWITCH, Emergency stop (base)
S3 138277 1 SWITCH, Base/off/platform (base) (ANSI/CSA, AS & KC)
S3 144366 1 SWITCH, Base/off/platform (base) (CE)
S4 144647 1 SWITCH, Emergency stop (platform)
S5 144648 1 SWITCH, Horn (platform)
S6 700187 1 FOOTSWITCH (platform)
S7 102853 1 SWITCH, Riser up/down (platform)
S8 102853 1 SWITCH, Telescope in/out (platform)
S9 102853 1 SWITCH, Jib up/down (platform)
S10 102853 1 SWITCH, Jib rotate (platform) (SJ30ARJE)
S11 102853 1 SWITCH, Platform rotate (platform)
S12 102853 1 SWITCH, Platform leveling (platform)
S13 102853 1 SWITCH, Platform leveling (base)
S14 102853 1 SWITCH, Platform rotate (base)
S15 102853 1 SWITCH, Jib rotate (base)
S16 102853 1 SWITCH, Jib up/down (base)
S17 102853 1 SWITCH, Telescope in/out (base)
S18 102853 1 SWITCH, Riser up/down (base)
S19 102853 1 SWITCH, Turret left/right (base)
S20 102853 1 SWITCH, Boom up/down (base)
S21 102853 1 SWITCH, Function enable (base)
S22 102853 1 SWITCH, Work light (platform)
S23 102853 1 SWITCH, Emergency pump (base)
S24 102853 1 SWITCH, Emergency pump (platform)
S25 166087 1 SWITCH, SGE reset (platform)
