SMA CLUSTER CONTROLLER Installation Manual

SMA Solar Technology AG 4 Product Description
Installation Manual ClusterController-IA-en-10 17
Symbols on the Type Label
4.3 LEDs
Operation LEDs
Symbol Designation Explanation
C-Tick The product complies with the requirements
of the applicable Australian EMC standards.
Indoor The device is only suitable for indoor
mounting.
FCC marking The product complies with the requirements
of the applicable FCC standards.
CE marking The product complies with the requirements
of the applicable EC directives.
WEEE designation Do not dispose of the product together with
the household waste but only in accordance
with the locally applicable regulations for
disposal of electronic waste.
Data matrix code 2D code for device-specific characteristics
LED Designation Explanation
Power LED Displays whether the Cluster Controller is starting
or is in operation (for a description of the LED
statuses, see Section 7.1.1)
Status LED Displays the status of the Cluster Controller and
the connected devices as well as the
communication status of the plant and the status
of the grid management (for a description of the
LED statuses, see Section 7.1.1)
Data carrier status LED Displays the status of the connected USB data
carrier (for a description of the LED statuses, see
Section 7.1.1)

SMA CLUSTER CONTROLLER Specifications

General

Data Logging	Yes
Display	LCD
Power Supply	24 V DC
Remote Monitoring	Yes
Protection Class	IP20
Communication Interfaces	Ethernet
Product Type	Controller
Manufacturer	SMA
