9 Technical Data SMA Solar Technology AG

80 ClusterController-IA-en-10 Installation Manual

Analogue Outputs

Temperature Inputs

USB Terminals

Number of analogue outputs for current signals 2

Measurement range for current signals 4 mA … 20 mA

Maximum tolerance ± 0.5%

Maximum cable length 3,000 m

Quantity 2

Measuring shunt Printed circuit board sensor PT100,

printed circuit board sensor PT1000

Type of measurement Two-conductor connection, four-conductor

connection

Measuring range − 40°C … +85°C

Maximum tolerance*

* for measuring with four-conductor connection

± 0.5°C

Maximum cable length* 20 m

Quantity 2

Specification USB 2.0 Hi-Speed

Maximum current 500 mA

Maximum cable length 3 m
