SMA CLUSTER CONTROLLER Installation Manual

SMA Solar Technology AG 9 Technical Data
Installation Manual ClusterController-IA-en-10 77
9 Technical Data
General Data
Mechanical Data
Display
Memory
Voltage supply
Status display LEDs, display
Operation Button field, integrated Web server
Type of mounting Top-hat rail mounting
Mounting location Indoors
Width x height x depth 275 mm x 133 mm x 71 mm
Weight 1.2 kg
Display LCD display
Resolution 240 px × 64 px
Display languages German, English
Operation Button field
Internal ring buffer 1.7 GB
External memory*
*optional
USB data carrier
Voltage supply Top-hat rail power supply
Input voltage 18 V DC … 30 V DC
Typical power consumption 24 W
Maximum power consumption 30 W

SMA CLUSTER CONTROLLER Specifications

General

Data Logging	Yes
Display	LCD
Power Supply	24 V DC
Remote Monitoring	Yes
Protection Class	IP20
Communication Interfaces	Ethernet
Product Type	Controller
Manufacturer	SMA
