SMA CLUSTER CONTROLLER Installation Manual

SMA Solar Technology AG 7 Troubleshooting
Installation Manual ClusterController-IA-en-10 65
7 Troubleshooting
7.1 LED States
7.1.1 Operation LEDs
Configuration of the status LED ( )
The status LED can display the following statuses:
• Status of the Cluster Controller
• Status of the connected inverters
• Status of the plant communication
• Status of the grid management
In this document, the only states described below are those that the status LED can adopt upon initial
start-up (for a complete description of the states, see the Cluster Controller user manual).
• If the status LED is not glowing green after commissioning, refer also to the event log of the
Cluster Controller to determine the precise cause of the fault. The details of the respective fault
are logged in the event log (see the Cluster Controller user manual).
LED Status Cause and corrective measures
All Off The Cluster Controller is not connected to the voltage
supply.
Corrective measures:
• Connect the Cluster Controller to the voltage
supply (see Section 6.13).
The voltage supply is reverse-connected or the top-hat
rail power supply unit is defective.
Corrective measures:
• Ensure that the voltage supply is correctly
connected (see Section 6.13).
• If the voltage supply is correctly connected,
replace the top-hat rail power supply unit.
Power ( ) and status
()
Power glowing
red, status
glowing
yellow or red
The voltage supply is too low.
Corrective measures:
• Ensure that the connected voltage supply is
sufficient (see Section 6.13).
• If the problem persists, contact the
SMA Service Line (see Section 11).
Power Glowing
green
The start procedure is complete. The Cluster Controller
is ready for operation.

SMA CLUSTER CONTROLLER Specifications

General

Data Logging	Yes
Display	LCD
Power Supply	24 V DC
Remote Monitoring	Yes
Protection Class	IP20
Communication Interfaces	Ethernet
Product Type	Controller
Manufacturer	SMA
