SMA Solar Technology AG 4 Product Description
Installation Manual ClusterController-IA-en-10 19
Overview of the Display Views
Display view Explanation
Start view Displays when the Cluster Controller starts up and includes the
current firmware version of the Cluster Controller
Plant overview Displays the plant status, the current daily yield, the plant power
and the current setpoints for active power and reactive power
If no button on the button field is pressed within five minutes, the
Cluster Controller switches to the Plant overview display view.
Yield data Displays the yield data of the plant
Plant status Displays the current plant status
The number of inverters detected by the Cluster Controller and the
status of the inverters is displayed here
Cluster Controller Displays the status and device information of the
Cluster Controller
When a USB data carrier is inserted into USB terminal 1,
information on the current memory usage of the USB data carrier
will be displayed.
Sunny Portal settings Displays the configured upload frequency and the date of the last
successful data upload to Sunny Portal
Analogue inputs Displays the analogue inputs with the current level value and unit
Digital inputs Displays the digital inputs in binary form
The digital inputs are summarised in two groups here.
Meteorology Displays the measured values of the connected irradiation sensor
and the connected temperature sensors
Active power limitation Displays the current setpoint for active power limitation with the
data of the last change to the configuration
Reactive power setpoint Displays the current reactive power setpoint and the date of the
last change to the configuration
Grid management Displays the selected setpoint type and the signal sources for the
grid management via the user interface of the Cluster Controller
External communication Displays the settings for the local area network (LAN)
Speedwire Displays the settings in the Speedwire network
Modbus settings Displays the Modbus settings with the activated network protocols
and the corresponding network ports
Settings Enables the display contrast to be changed and the Cluster
Controller to be partially or fully reset (see Section 7.3)
