SMA CLUSTER CONTROLLER Installation Manual

6 Connection SMA Solar Technology AG
28 ClusterController-IA-en-10 Installation Manual
Inverter (Speedwire) ☐ Cable category: from Cat5
☐ Cable structure and shielding: S/UTP, SF/UTP (S-FTP* ),
S/FTP (S-STP*) or SF/FTP
☐ Maximum cable length between two nodes when using patch
cables: 50 m
☐ Maximum cable length between two nodes when using
installation cables: 100 m
☐ When using self-assembly patch cables: two RJ45 connectors
per cable
Local area network (LAN) ☐ Cable category: from Cat5
☐ Cable structure and shielding: S/UTP, SF/UTP (S-FTP*),
S/FTP (S-STP*) or SF/FTP
☐ Maximum cable length between two nodes when using patch
cables: 50 m
☐ Maximum cable length between two nodes when using
installation cables: 100 m
☐ When using self-assembly patch cables: two RJ45 connectors
per cable
* Designation according to an older standard
Connection Cable requirements

SMA CLUSTER CONTROLLER Specifications

General

Data Logging	Yes
Display	LCD
Power Supply	24 V DC
Remote Monitoring	Yes
Protection Class	IP20
Communication Interfaces	Ethernet
Product Type	Controller
Manufacturer	SMA
