SMART Board GX Series - Commands

Appendix C
Managing the display using RS-232
smarttech.com/kb/171744 92
Commands
Function Set command Get command Response
Power state k01sA00[Value]<CR>
Where [Value] is one of the
following:
l 0 (standby)
l 1 (on)
k01gi000<CR> Now [Value]<CR>
Where [Value] is one of the
following:
l
ON
l
Standby
Input k01sB0[Value]<CR>
Where [Value] is one of the
following:
l 00 (ATV)
l 01 (AV)
l 03 (YPBPR)
l 04 (HDMI)
l 06 (VGA)
l 07 (OPS1)
l 09 (Display Port)
l 10 (DTV)
l 0A (Home)
l 0C USB-C
l 14 (HDMI1)
l 24 (HDMI2)
k01gh000<CR> k01rh[Value]<CR>
Where [Value] is one of the
following:
l X01 (AV input)
l X03 (YPBPR)
l X04 (HDMI)
l X14 (HDMI1)
l X24 (HDMI2)
l X07 (OPS1)
l X09 (Display Port)
l 10A (Home screen)
l X1C (USB-C)
The “X” in the response can be
either “0” or “1”.
“0” indicates that the video
input does NOT have a video
signal. “1” indicates that the
video input DOES have a video
signal.
Picture size k01sM004<CR> [N/A] [N/A]
Volume k01sP[Value]<CR>
Where [Value] is one of the
following:
l
0–100
NOTE
Volume level is set by
entering a number
between 0 and 100
l 200 (-1 level)
l 201 (+1 level)
k01gf000<CR> k01rf[Value]<CR>
Where Value is a number
between 0 and 100.
