HRSH Series 8.5 Pump capacity
8-9
8.5.2 HRSH250-A∗-20／40-∗
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
0 20 40 60 80 100 120 140 160 180
Circulating fluid flow [L/min]
Pressure [MPa]
0
10
20
30
40
50
60
70
80
90
Lifting head [m]
Fig. 8-8 Pump capacity (HRSH250-A∗-20／40-∗)
Usable flow rate ran
g
e
Circulating fluid
return
Circulating fluid
outlet
