SMC Networks HRSH200-A*-20 Series - Moving by Forklift and Slinging

HRX-OM-Q026-B
Chapter 3 Transport and Setting Up
3.1 Transport HRSH Series
3-2
3.1.1 Moving by forklift and slinging
Fig 3-1 Fork insert and slinging position
The wights of the product are HRSH150/200：Approx. 215kg,
HRSH250：Approx. 280kg.
Moving by forklift and slinging should be done by persons who have
the licenses.
Position to sling
Less than 60°
Fork insert position
Fork Insert position
