HRX-OM-Q026-B
Chapter 3 Transport and Setting Up
HRSH Series 3.2 Installation
3-7
3.2.3 Installation and Maintenance Space
It is recommended to keep the space around the product shown in Fig. 3-3.
Fig. 3-3 Installation space
Have an enough space for the ventilation for the product. Otherwise it
may cause a lack of cooling capacity or/and stoppage of the product.
Have an enough space for maintenance.
Top
Front
